CZ-standard chemical process pump

FEATURES

Cz series standard chemical process pump is horizontal, single stage, single suction, radial profile separation heart pump. Its size and performance meet the standard of 1S02858. The pressure on the at the shaft seal are balanced by the balance hole on the side blade or the impeller.Shaft seal can be packed or mechanical seal, such as single or double seal, with a variety of sealing systems,The rear door structure and the lengthened coupling design can remove the whole rotor without removing the pump body and motor during maintenance,Flange  inlet and outlet flange pressure levels have the same design level.The design standard is 2.5mpa, or 1.6mpa or ANSI150#

Performance parameter

Specification; DN: 32~ 300mm

Flow:    Q: ~2000m³/h;

Lift Head: H: ~160m;

Working Pressure: P: ~ 2.5Mpa

Working Temperature: T: ~260℃

Work media

Organic and inorganic acids such as nitric acid, sulfuric acid, hydrochloric acid and phosphoric acid.

Sodium hydroxide or sodium carbonate, etc. alkaline solution.

Salt solution.

Liquid petrochemical products, organic compounds and other corrosive raw materials and products.

Scope of application

It is widely used in chemical and petrochemical/industrial refinery/paper mill and pulp mill/production equipment of sugar industry.
