Product introduction:
1. FSB fluorine plastic chemical pump acid resistant monoblock pump is applied to convey acid, oxidant, corrosive medium with physical property similar to water.
2. The monoblock pump is with the merits of reasonable design, strong corrosion resistance ability, high mechanical strength, nonaging, and easy of maintenance.
3. Wet parts are made of fluorine plastic or polyethylene, and the pump could be designed to direct connect type or shaft contact type.
4. The acid-resistant pump is widely used in the fields of chemical industry, petrol, medicine, pesticide, dye, smelting, paper making, plating, etc.
Product details:
| Working Principle: | Centrifugal |
| Main applications: | Chemical |
| Driver: | Electric motor |
| Power Specs: | 220/380/400/415V 3phase;50hz/60hz |
| Max. permissible fluid temperature: | 80°C(176°F) |
| Type of connection: | Flange |
| Installation position: | Horizontal |
| Casing parts material: | Fluoroplastic, polyethylene, etc |
| Shaft seal type: | Mechanical seal |
| Free passage: | 0mm |
| Maximum drive rating: | 75KW(100HP) |
| Maximum caliber: | 200mm(8inch) |
| Maximum discharge-side pressure: | 0.8MPa(8bar) |
| Maximum head: | 80m(262.4ft) |
| Flow rate range: | 1.5-400m3/h(6.6-1760US.GPM) |
Performance data:
| Model | Capacity | Head | Inlet | Outlet | Power | Speed | Suction | Efficiency |
| (m3/h) | (m) | (mm) | (mm) | (KW) | (r/min) | (m) | (%) | |
| 25FSB-10L | 1.5 | 10 | 25 | 20 | 2.2 | 2900 | 6 | 29 |
| 25FSB-18L | 3.6 | 18 | 25 | 20 | 2.2 | 2900 | 6 | 27 |
| 40FSB-15L | 10 | 15 | 40 | 32 | 3 | 2900 | 6 | 40 |
| 40FSB-20L | 10 | 20 | 40 | 32 | 3 | 2900 | 6 | 42 |
| 40FSB-30L | 10 | 30 | 40 | 32 | 3 | 2900 | 6 | 38 |
| 40FSB-40L | 10 | 40 | 40 | 32 | 4 | 2900 | 5.5 | 35 |
| 40FSB-50L | 10 | 50 | 40 | 32 | 5.5 | 2900 | 5 | 33 |
| 50FSB-20L | 15 | 20 | 50 | 40 | 4 | 2900 | 6 | 51 |
| 50FSB-25L | 15 | 25 | 50 | 40 | 4 | 2900 | 6 | 49 |
| 50FSB-30L | 15 | 30 | 50 | 40 | 4 | 2900 | 6 | 44.5 |
| 50FSB-40L | 15 | 40 | 50 | 32 | 5.5 | 2900 | 5.5 | 35 |
| 50FSB-50L | 15 | 50 | 50 | 32 | 7.5 | 2900 | 5.5 | 33 |
| 65FSB-32L | 29 | 32 | 65 | 50 | 5.5 | 2900 | 6 | 57 |
| 65FSB-40L | 29 | 40 | 65 | 40 | 7.5 | 2900 | 5.5 | 53 |
| 65FSB-50L | 29 | 50 | 65 | 40 | 11 | 2900 | 5.5 | 46 |
| 80FSB-20L | 50 | 20 | 80 | 65 | 7.5 | 2900 | 6 | 69 |
| 80FSB-30L | 50 | 30 | 80 | 65 | 7.5 | 2900 | 5.5 | 64 |
| 80FSB-34L | 50 | 34 | 80 | 65 | 11 | 2900 | 5.5 | 64 |
| 80FSB-38L | 50 | 38 | 80 | 50 | 11 | 2900 | 5.5 | 60 |
| 80FSB-50L | 50 | 50 | 80 | 50 | 15 | 2900 | 6 | 53 |
| 80FSB-80L | 50 | 80 | 80 | 50 | 22 | 2900 | 5.5 | 36 |
| 100FSB-32L | 100 | 32 | 100 | 80 | 18.5 | 2900 | 5.5 | 70 |
| 100FSB-40L | 100 | 40 | 100 | 80 | 22 | 2900 | 5.5 | 70 |
| 100FSB-50L | 100 | 50 | 100 | 65 | 30 | 2900 | 5.5 | 62 |
| 125FSB-32L | 200 | 32 | 125 | 80 | 30 | 2900 | 5.5 | 72 |
| 125FSB-50L | 200 | 50 | 125 | 100 | 45 | 2900 | 5.5 | 64 |
| 150FSB-32L | 200 | 32 | 150 | 100 | 30 | 1450 | 5.5 | 77 |
| 150FSB-50L | 200 | 50 | 150 | 100 | 55 | 1450 | 5 | 75 |
