Overview：
The G series sludge screw pump is a kind of internally meshing closed screw pump, which is a rotor-type positive displacement pump. The screw pump has strong adaptability to the medium, stable flow, small pressure pulsation, good suction performance, and can transport all kinds of flow In addition to the media, it can also transport highly viscous media, media containing hard suspended particles or solid particles, and media containing fibers, with good adjustment performance, wide range, and high efficiency.
Performance range:
|
Model number
|
G50-1
|
|||
|
Place of origin
|
Jiangsu, China
|
|||
|
Horsepower
|
3HP
|
|||
|
Outlet size
|
50mm
|
|||
|
Voltage
|
380V、440V
|
|||
|
Flow
|
10m³/h
|
|||
|
Head
|
60m
|
|||
|
Warranty
|
1year
|
|||
Application range：
G series sludge screw pump is used in the food, chemical industry, petroleum, power plant, papermaking, metallurgy, mining industry, sewage, river pond dredging, etc., supporting filter press, high-lift conveying materials (honey, bean paste, mud, mortar, chemical Liquid, liquid medicine)
Performance parameter table：
|
Type
|
Capacity
|
Pressure
|
Speed
|
Motor Power
|
NPSH
|
Inlet diameter
|
Outlet diameter
|
Allowable particle diameter
|
Allowable fiber length
|
|
(m³ / h)
|
(Mpa)
|
(r/min)
|
(kw)
|
(m)
|
(mm)
|
(mm)
|
(mm)
|
(mm)
|
|
|
G20-1
|
0.8
|
0.6
|
960
|
0.75
|
4
|
25
|
25
|
1.5
|
25
|
|
G20-2
|
0.8
|
1.2
|
960
|
1.5
|
4
|
25
|
25
|
1.5
|
25
|
|
G25-1
|
2
|
0.6
|
960
|
1.5
|
4
|
32
|
25
|
2
|
30
|
|
G25-2
|
2
|
1.2
|
960
|
2.2
|
4
|
32
|
25
|
2
|
30
|
|
G30-1
|
5
|
0.6
|
960
|
2.2
|
4
|
50
|
40
|
2.5
|
35
|
|
G30-2
|
5
|
1.2
|
960
|
3
|
4
|
50
|
40
|
2.5
|
35
|
|
G35-1
|
8
|
0.6
|
960
|
3
|
4
|
65
|
50
|
3
|
40
|
|
G35-2
|
8
|
1.2
|
960
|
4
|
4
|
65
|
50
|
3
|
40
|
|
G40-1
|
12
|
0.6
|
960
|
4
|
4
|
80
|
65
|
3.8
|
45
|
|
G40-2
|
12
|
1.2
|
960
|
5.5
|
4
|
80
|
65
|
3.8
|
45
|
|
G50-1
|
20
|
0.6
|
960
|
5.5
|
4.5
|
100
|
80
|
5
|
50
|
|
G50-2
|
20
|
1.2
|
960
|
7.5
|
4.5
|
100
|
80
|
5
|
50
|
|
G60-1
|
30
|
0.6
|
960
|
11
|
5
|
125
|
100
|
6
|
60
|
|
G60-2
|
30
|
1.2
|
960
|
15
|
5
|
125
|
100
|
6
|
60
|
|
G70-1
|
45
|
0.6
|
720
|
11
|
5
|
150
|
125
|
8
|
70
|
|
G70-2
|
45
|
1.2
|
720
|
18.5
|
5
|
150
|
125
|
8
|
70
|
|
G85-1
|
65
|
0.6
|
630
|
15
|
5
|
150
|
150
|
10
|
80
|
|
G85-2
|
65
|
1.2
|
630
|
30
|
5
|
150
|
150
|
10
|
80
|
|
G105-1
|
100
|
0.6
|
500
|
30
|
5
|
200
|
200
|
15
|
110
|
|
G105-2
|
100
|
1.2
|
500
|
55
|
5
|
200
|
200
|
15
|
110
|
|
G135-1
|
150
|
0.6
|
400
|
45
|
5
|
250
|
250
|
20
|
150
|
|
G135-2
|
150
|
1.2
|
400
|
90
|
5
|
250
|
250
|
20
|
150
|
