Overview：
IHG vertical pipeline centrifugal pump for seawater/ hydrant vertical water pump station firefighting uses a water pump, diesel engine pump, and jockey pump used for fire fighting systems. Fire pumps are required to comply with Local Civil Defense Authority regulations and International Codes of Practice e.g. National Fire Protection Association (NFPA).
This series of products has the characteristics of high efficiency, energy saving, low noise, and reliable performance. And can be equipped with an explosion-proof motor according to user needs.
Product Usage
ISG vertical pipeline pump is used for conveying clear water and other liquids whose physical and chemical properties are similar to clear water. It is suitable for industrial and urban water supply and drainage, pressurized water supply for high-rise buildings, garden sprinkler irrigation, fire pressurization, long-distance transportation, and HVAC refrigeration cycle. Cold and hot water circulation pressurization and equipment matching for bathrooms, etc., the operating temperature T≤80°C.
Performance range:
| Flow rate | Max-720 m3/h |
| Head | Max-250 m |
| Speed | 2900-1450r/min |
| Temperature | -20℃ +150℃ |
| Max pressure | 2.5 Mpa |
| Material | Cast/Stainless steel 304 316 .etc |
| Temperature | -80℃-+300℃ |
| Type | Horizontal |
| Seal | Mechanical seal, packing seal.etc |
| Theory | Centrifugal pump |
| Medium | Water, low or high temperature, oil, Corrosive liquids. |
Performance parameter table：
|
Model
|
Flow
|
Head
(m)
|
Efficiency
(%)
|
Rotating speed
(r/min)
|
Motor power
(kw)
|
NPSH(r)
|
Weight
(kg)
|
|
|
m3/h
|
L/s
|
|||||||
|
15-80
|
1.1
1.5
2.0
|
0.3
0.42
0.55
|
8.5
8
7
|
26
34
34
|
2800
|
0.18
|
2.3
|
17
|
|
20-110
|
1.8
2.5
3.3
|
0.5
0.69
0.91
|
16
15
13.5
|
25
34
35
|
2800
|
0.37
|
2.3
|
25
|
|
20-160
|
1.8
2.5
3.3
|
0.5
0.69
0.91
|
33
32
30
|
19
25
23
|
2900
|
0.75
|
2.3
|
29
|
|
25-110
|
2.8
4
5.2
|
0.78
1.11
1.44
|
16
15
13.5
|
34
42
41
|
2900
|
0.55
|
2.3
|
26
|
|
25-125
|
2.8
4
5.2
|
0.78
1.11
1.44
|
20.6
20
18
|
28
36
35
|
2900
|
0.75
|
2.3
|
28
|
|
25-125A
|
2.5
3.6
4.6
|
0.69
1.0
1.28
|
17
16
14.4
|
35
|
2900
|
0.55
|
2.3
|
27
|
|
25-160
|
2.8
4
5.2
|
0.78
1.11
1.44
|
33
32
30
|
24
32
33
|
2900
|
1.5
|
2.3
|
39
|
|
25-160A
|
2.6
3.7
4.9
|
0.12
1.03
1.36
|
29
28
26
|
31
|
2900
|
1.1
|
2.3
|
34
|
|
32-100
|
4.5
|
12.5
|
12.5
|
44
|
2900
|
0.55
|
2.0
|
27
|
